Αlso known as: Ζ-9
Technical specifications
| DESIGNER | Harbin (HAMC) |
| COUNTRY | China |
| TYPE |
Attack helicopter
|
| CREW | 2 |
| POWER-PLANT | Two Turbomeca Arriel IM1 turboshaft engines |
| Power, h.p. | 2x794 |
|
DIMENSIONS
|
|
|
Length, m
|
13,46
|
|
Main rotor diameter, m
|
12,00
|
|
Tail rotor diameter, m
|
1,10
|
|
Height, m
|
3,47
|
| WEIGHT | |
| Maximum take-off, kg | 4.100 |
| Normal take-off, kg | 4.060 |
| Empty aircraft, kg | 2.050 |
| Internal fuel, kg | - |
| Weight of transported fuel with external tanks, l | - |
| Warload, kg | - |
| Payload, kg | |
| - passengers or soldier | 10 |
| - freight in cabin | 1.863 |
| - with on hook | 1.600 |
| PERFORMANCE | |
| Maximum speed, km/h | 305 |
| Cruising speed, km/h | 260 |
|
Combat range, km
|
400 |
| Range, km | 1.000 |
|
Service ceiling, m
|
6.000
|
|
Static ceiling, m
|
2.600
|
|
Rate of climb, m/min
|
420
|
| ARMAMENT | Doesn't have (defensive). Newer versions are given the ability to carry weaponry a 23mm Type 23-1 gun. Number external hardpoints: 4. Four HJ-8E anti-tank missile launchers or 2 57 mm or 90 mm rocket pods or 2 TY-90 air-to-air missiles or 2 12.7 mm cannon pods. |
