Technical specifications
| DESIGNER | Belyaev |
| COUNTRY | Russia |
| TYPE |
Long-range bomber
|
| CREW | 4 |
| POWER-PLANT | Two piston engines M-87B |
| Power, h.p. | 2x950 |
| DIMENSIONS | |
| Length, m | 9,78 |
| Height, m | 3,65 |
| Wing span, m | 21,60 |
| Wing area, m2 | 56,87 |
| WEIGHT | |
| Maximum take-off, kg | 10.672 |
| Normal take-off, kg | 9.061 |
| Empty aircraft, kg | 6.004 |
| Internal fuel, kg | - |
| Warload, kg | 2.000 |
| PERFORMANCE | |
| Maximum speed, km/h | 488 |
| Max speed in low height, km/h | 395 |
| Cruising speed, km/h | 466 |
| Range, km | 1.270 |
| Combat range, km | - |
| Service ceiling, m | 8.500 |
| Rate of climb, m/min | 370 |
| Maximum overload, g | - |
| ARMAMENT | 6x7,62 mm machine-gun ShKAS. |
